6-3 PT Operating Settings
6-15
6-3
PT Operating Settings
The PT
T
ab Page is used to set the following functions.
•
Star
t-
up wait time
•
Scr
een sav
er
•
Ke
y
press sound
•
Buzzer s
ound
•
Backlight
•
Contrast (N
S7 only)
•
Calendar c
heck
PT
T
ab P
age for the NS12
PT
T
ab P
age for the NS10 and NS7
(NS10 has no contras
t adjustment.)
