3-7 Installing the Video Input Unit
3-27
3-7 Installing the Video Input Unit
A Video Input Unit (NS-CA001) can be mounted to an NS-series PT. Mounting a Video Input
Unit allows images from a video camera or vision sensor to be displayed on the PT screen.
This section explains how to connect a Video Input Unit to the PT with a cable. The Video In-
put Unit can be mounted to NS12 and NS10 PTs only. It cannot be mounted to an NS7 PT.
3-7-1 Video Input Unit Components
The following table shows the Video Input Unit's product configuration.
Model Components
Name Contents
NS-CA001
Video Input Unit
Video Board (1) Allows video input.
Cover (1) Protects Video Board.
Cable (1) Connects the PT's functional ground
terminal and the cover to prevent
noise.
Screw (M3) (9) These screws are used for the fol-
lowing:
-Securing the Video Board to the
back of the PT.
-Securing the cover to the back of
the PT.
-Attaching the cable to the cover.
Instruction sheet Instruction sheet for NS-CA001.
Note To comply with EC Directives (Low Voltage Directive) when mounting the Video Input Unit on
the PT, attach the PT to a control panel that has been cut to fit the size. (Refer to 3-1-3
Mounting the PT to the Control Panel for panel cutout dimensions.)
