5-2 Connecting to the Host Using Controller Link
5-22
Indicators Probable cause Remedy
RUN ERC ERH INS
Lit
-
Lit
-
Routing table setting error. Remake and set the routing tables cor-
rectly, referring to Section 7 System Set-
tings in the NS-Designer Operation Manual.
When the routing tables are not being used,
delete the routing tables.
EEPROM error. Send a FINS command to the Controller
Link Interface Unit to read status, correct
the data where the error has occurred, and
reset the Board. If the error occurs again,
replace the Controller Link Interface Unit.
Lit
--
Not lit Terminating resistance is not set
correctly.
Turn ON the terminating resistance at the
nodes at both ends of the network and turn
it OFF at all other nodes.
Cables are not connected correctly. Check the cable connections and reconnect
correctly.
The node address is larger than the
maximum node address set for the
network parameters.
Either reset the maximum node address
using Controller Link Support Software or
reset the node address to below the maxi-
mum.
No other nodes exist. Ensure that 2 or more nodes exist within the
Network.
No nodes have been set as polling
node.
Set the polling node using the CX-Server.
The set baud rate is different from
other nodes.
Reset the baud rate for the Controller Link
in the System Settings of the NS-Designer.
Refer to Section 7 System Settings in the
NS-Designer Operation Manual.
