254
Auxiliary Area and CIO Area Allocations Section 7-3
7-3 Auxiliary Area and CIO Area Allocations
This section describes the bits and words used by the Serial Communications
Board and Serial Communications Units in the Auxiliary Area and the Status
Area and Software Switches allocated in the CIO Area used for no-protocol
communications.
Auxiliary Area Allocations
Port 1 and Port 2 Port Settings Change Bits
These bits can be turned ON from the program using the OUT or other
instructions to change communications settings and restart the serial port.
When changing the settings and restarting the port have been completed, the
bit will automatically be turned OFF.
Note These bits are used both to change the port settings and to restart the port at
the same time. One of these bits can be turned ON to restart a port without
changing the port settings in the Setup Area allocated in the DM Area. The
STUP(237) instruction can also be used to just restart a communications port
by executing STUP(237) with the same port settings as the ones already
being used.
Serial Communications Boards (CS Series only)
D32001 D32011 m+1 m+11 04 to 15 Reserved
00 to 03 Baud rate (bps)
0: Default (9,600); 3: 1,200; 4: 2,400; 5: 4,800; 6: 9,600; 7: 19,200;
8: 38,400; 9: 57,600
D32002 D32012 m+2 m+12 15 Send delay time 0: Default (0 ms); 1: Setting in bits 00 to 14
00 to 14 Send delay setting range: 0 to 300 s (0 to 300,000 ms): 0000 to
7530 hex (0 to 30,000 decimal) (Unit: 10 ms)
D32003 D32013 m+3 m+13 15 CTS control 0: No; 1: Yes
D32004 D32014 m+4 m+14 08 to 15 Start code: 00 to FF hex
00 to 07 End code: 00 to FF hex
D32005 D32015 m+5 m+15 12 Start code 0: No; 1: Yes
08 to 09 End code
00: No (Specify number of receive data bytes)
01: Yes
10: CR + LF specification
00 to 07 Number of receive data bytes
01 to FF hex: 1 to 255 bytes
00 hex (default): 256 bytes
Words Bit Setting contents
Board
(CS Series only)
Unit
(CS/CJ Series)
Port 1 Port 2 Port 1 Port 2
Word Bit Contents
A636 03 to 15 Reserved
02 1: Port 2 Settings Change Bit
01 1: Port 1 Settings Change Bit
00 Reserved
To Next Page
