Error Logs Section 11-4
11-4 Error Logs
The error log function records the errors detected in the Serial Communica-
tions Board or Serial Communications Unit together with the time that the
error occurred.
11-4-1 Error Log Table
RAM Error Log Table For every error that occurs, one record is logged in the RAM error log table in
the Board or Unit for up to 64 errors.
EEPROM Error Log Table Records of errors that are particularly serious are logged in both the RAM
error log table and the EEPROM error log table in the Board or Unit when they
occur. The contents of errors logged in the EEPROM error log table remain
even if the power to the Board or Unit is turned OFF or the Board or Unit is
restarted. The contents of the EEPROM error log table is automatically read
to the RAM error log table when the power is turned ON. One record is logged
in the EEPROM error log table for each error that occurs for up to 32 errors
max.
11-4-2 Error Log Specifications
When the number of errors recorded in the RAM error log table reaches 64 (or
32 records for the EEPROM error log table), the oldest records will be deleted
to store the most recent errors.
Item Specifications
Record length 10 bytes per record
Record configuration
Error code: 2 bytes
Details: 2 bytes
Time: 6 bytes
Data format Binary (time information is in BCD)
Number of records
RAM: 64 records max.
EEPROM: 32 records max.
Storage order Records are stored in order from the oldest to the
most recent errors.
