Status Area Error Indications Section 11-2
11-2 Status Area Error Indications
This section describes status area error information.
Status Area Error
Information
When an error occurs, the corresponding flag is turned ON.
n = CIO 1500 + 25
× unit number
Lit Not lit Not lit Lit
A Protocol Data File (BACKUP
@@.PRM) was
read (restored) from the CPU Unit’s Memory
Card to the Serial Communications Unit prop-
erly.
---
Lit Flash-
ing
--- Flash-
ing
A protocol data write error has occurred or
protocol data has been destroyed.
There is no protocol data.
If the indicator status remains the same
when the protocol data is retransmitted,
replace the Unit.
Transfer protocol data to the Unit.
Lit Flash-
ing
--- Lit A protocol data syntax error has occurred. Correct the protocol data and transfer it
to the Unit.
The ERC indicator can also be turned
OFF by executing a normal sequence for
the serial port for which the error is
occurring or by switching the CPU Unit to
PROGRAM mode temporarily.
Lit Lit --- Flash-
ing
• The flash memory for protocol data is
faulty.
• The Protocol Data File (BACKUP
@@.PRM)
restore operation failed when restoring pro-
tocol data from the CPU Unit’s Memory
Card to the Serial Communications Unit.
• Transfer the protocol data to the Unit.
If the problem persists after correct
protocol data is transferred, replace
the Unit.
• Write (backup) the protocol data from
the Unit to the Memory Card again
and then execute the restore opera-
tion again.
• If the restore operation fails two times
in succession, use CX-Protocol to
transfer the protocol data to the Serial
Communications Unit.
Indicators Possible cause Remedy
RUN ERC ERH RDY
Word Bit Flag name Possible cause Remedy
Boards
(CS Series only)
Units
(CS/CJ Series)
CIO 1901 n + 1 01 Error Log data
error
The error log
EEPROM is faulty.
If the problem persists even if the
power supply is cycled, replace
the Board/Unit.
00 Protocol data
error
A protocol data
checksum error has
occurred.
If the error persists when protocol
data is retransmitted, replace the
Board or Unit.
CIO
1906
CIO
1916
n + 6 n + 16 01 System Setup
error
A System Setup
error has occurred.
Correct the Setup Area settings,
cycle the power supply, restart
the Unit/Board, or restart the
port, or execute the STUP(237)
instruction.
CIO
1907
CIO
1917
n + 7 n + 17 10 Remote node
receive busy
The remote node is
in reception buffer
busy status when
flow control is set for
the protocol.
Cancel the communications with
the remote node until this flag is
turned OFF.
08 Local node
receive busy
The local node is in
reception buffer busy
status.
Increase the transmission interval
to reduce transmission load to
the remote node for which flow
control is set.
