Auxiliary Area and CIO Area Allocations Section 8-3
8-2-2 Setup Area Contents
m = D30000 + 100 × unit number
Note With CS-series, a high-speed NT Link is available only with Serial Communi-
cations Boards or Serial Communications Units manufactured on or after
December 20th, 1999. With earlier models, only standard NT Link is available.
Except for the baud rate, the 1:N NT Link communications specifications are
fixed. Therefore, the port settings, start bits, stop bits, and parity need not be
set. Even if they are set, they are ignored.
Serial Communications
Mode
Set the serial communications mode to 2 Hex to use 1:N NT Link mode.
Maximum 1:N NT Links
Unit No.
With 1:N NT Links, up to eight Programmable Terminals (PTs) can be con-
nected. The highest connected unit number is set here.
8-3 Auxiliary Area and CIO Area Allocations
This section describes the bits and words used by the Serial Communications
Board and Serial Communications Units in the Auxiliary Area and the Status
Area allocated in the CIO Area. The Software Switches allocated in the CIO
Area are not used for 1:N NT Links.
DM Area Bit Setting contents
Boards
(CS Series only)
Unit
(CS/CJ Series)
Port 1Port 2Port 1Port 2
D32000 D32010 m m + 10 15
Port settings Setting not required.
12 to 14 Reserved
08 to 11 Serial communications mode: Always 2 Hex (1:N
NT Link)
05 to 07 Reserved
04
Start bits Setting not required.
03
Data length Setting not required.
02
Stop bits Setting not required.
01
Parity Setting not required.
00
Parity Setting not required.
D32001 D32011 m + 1 m + 11 04 to 15 Reserved
00 to 03 Baud rate (bps)
0 to 9 Hex: Standard NT Link
A Hex: High-speed NT Link (See note.)
D32006 D32016 m + 6 m + 16 03 to 15 Reserved
00 to 02 1:N NT Link Maximum unit number: 0 to
7 hex
Manufactured on December 20th, 1999
The year is indicated with the last digit. In this case, "9" indicates "1999."
Month of manufacture. October, November, and December are indicated
with X, Y, and Z respectively. In this case, the month is "December."
Day of manufacture. In this example, the day is "20."
NT31/631(C)-V2 are the only PTs for which high-speed NT link is supported.
Lot No:
20Z9
