Omron SYSMAC CJ1W-SCU21-V1 User Manual

543
Appendix J
E5@J Temperature Controller Protocol
The E5@J Temperature Controller Protocol performs various settings and controls in remote mode for the Tem-
perature Controller connected to the Serial Communications Unit/Board via RS-232C or RS-422A/485 cable.
Note Negative values cannot be written. All values must be set as unsigned BCD.
Structure of the Protocol
The following table shows the structure of the E5@J Temperature Controller Protocol.
Note 1. The hexadecimal equivalents of sequences numbers are given in parentheses.
2. Ladder Interface Settings
YES: User settings are required for the 3rd or 4th operands of PMCR.
NO: Send word allocation: Set the constant 0000 for the 3rd operand (S).
Receive word allocation: Set the constant 0000 for the 4th operand (D).
Sequence
No.
Communications
sequence name
Function Ladder interface
Send word
allocation
Receive word
allocation
200 (00C8) Select remote mode Switches the Controller to remote mode. Yes No
201 (00C9) Select local mode Switches the Controller to local mode. Yes No
202 (00CA) Select backup mode Switches from set point write mode to backup
mode.
Ye s N o
203 (00CB) Select RAM write mode Switches from set point write mode to RAM
write mode.
Ye s N o
204 (00CC) Save set point Saves the set point. Yes No
205 (00CD) Write parameters 1 Writes the set point, alarm value 1, alarm
value 2, and heater burnout alarm value.
Ye s N o
206 (00CE) Write parameters 2 Writes the proportional band, integral time,
and derivative time.
Ye s N o
207 (00CF) Write input shift value Writes the input shift value. Yes No
208 (00D0) Read parameters 1 Reads the set point, alarm value 1, alarm
value 2, and heater burnout alarm value.
Ye s Ye s
209 (00D1) Read parameters 2 Reads the proportional band, integral time,
and derivative time.
Ye s Ye s
210 (00D2) Read input shift value Reads the input shift value and writes it in
IOM.
Ye s Ye s
211 (00D3) Read output value Reads the output value and stores it in IOM. Yes Yes
212 (00D4) Read process value Reads the process value and stores it in
IOM.
Ye s Ye s
213 (00D5) Read set point limit Reads the set point limits and stores them in
IOM.
Ye s Ye s
214 (00D6) Read heater current Reads the heater current and stores it in
IOM.
Ye s Ye s
215 (00D7) Read initial status Reads the initial status and stores it in IOM. Yes Yes
216 (00D8) General-purpose write Writes the specified parameter by setting a
header code.
Ye s N o
217 (00D9) General-purpose read Reads the specified parameter by setting a
header code.
Ye s Ye s

Omron SYSMAC CJ1W-SCU21-V1 Specifications

General

Model	CJ1W-SCU21-V1
Type	Serial Communications Unit
Number of Ports	1
Parity Check	None, Even, Odd
Manufacturer	Omron
Operating Temperature	0 to 55 °C
Storage Temperature	-25 to 65 °C
Data Bits	7, 8
Stop Bits	1 or 2 bits
Flow Control	RTS/CTS
Isolation	Photocoupler isolation
Applicable PLC	CJ1 Series
Power Supply	5 VDC (supplied from the PLC backplane)
Compatible PLC Series	CJ1 Series
Protocol Support	NT Link, Host Link, No-protocol Mode
Baud Rate	300 to 115200 bps
