Initializing Settings Data
Initialization: This function resets all settings to their default values.
Default Values
Function Default Value
Display 0 reference: Measuring center distance
+ indication: NEAR side
- indication: FAR side
HIGH threshold Measuring range maximum value
LOW threshold Measuring range minimum value
Response time 500 ms
Analog output setting –5 to +5 V
Detail menu display
selection
OFF
Bank switching settings 0
Mutual interference
prevention
OFF
Hysteresis width 0.000
Two-Sensor operation
setting
OFF
Thickness setting 0.000
Measured value display
scaling
OFF
Hold setting OFF
Trigger mode TIMING (self-trigger timing input)
Self-trigger level 0.000
Output for non-
measurement
KEEP
Clamp level MAX
ON-delay time 0 ms
OFF-delay time 0 ms
Zero reset memory OFF
Display during zero
reset
0.000
External input terminal
setting
TIM.RST (timing input/reset input)
