Omron ZX2 Series User Manual

Part Names and Functions
21
ZX2 User’s Manual
INTRODUCTION
BASIC
SETUP
PREPARATION
FOR
MEASUREMENT
TROUBLE-
SHOOTING
INDEX
CONTENTS
SETTING
TRANSITION
CHARTS
FLOW OF
OPERATION
MAIN
APPLICATIONS
& SETTING
METHODS
DETAILED
SETTINGS
SPECIFI-
CATIONS
Height
Double
Sheet
Detection
Positioning
Eccentricity
and Surface
Deflection
Steps
and
Warpage
Thickness
Button Operation
The functions of buttons change according to the currently selected mode.
Button type Button function
RUN mode MENU mode
Cursor buttons
button
button
• Normal press:
Changes the sub-display content.
• Both buttons held down for
three seconds:
Locks button operation.
Function changes depending on the
setting.
• Switches the function display.
• Selects the digit of numerical values.
• Stops setting.
button • Normal press: Executes timing input. The function changes depending on
the setting.
• Changes the selection menu.
• Changes numerical values.
button • Held down for one second:
Executes zero reset.
• Both buttons held down for one
second:
Cancels a zero reset.
MENU/SET button • Held down for 3 seconds:
Changes the mode to the MENU
mode.
• Normal press:
Confirms the set condition or
value.
• Held down for 3 seconds:
Changes to the RUN mode.
Smart tuning button • Held down for one second, held
down for three seconds, held down
for five seconds:
Executes smart tuning.
• Held down for one second, held
down for three seconds, held down
for five seconds:
Executes smart tuning.
