Omron ZX2 Series User Manual

Specifications and Dimensions
115
ZX2 User’s Manual
INTRODUCTION
BASIC
SETUP
PREPARATION
FOR
MEASUREMENT
TROUBLE-
SHOOTING
INDEX
CONTENTS
SETTING
TRANSITION
CHARTS
FLOW OF
OPERATION
MAIN
APPLICATIONS
& SETTING
METHODS
DETAILED
SETTINGS
SPECIFI-
CATIONS
Height
Double
Sheet
Detection
Positioning
Eccentricity
and Surface
Deflection
Steps
and
Warpage
Thickness
(*1) In the case of a white ceramic OMRON standard object
(*2) In the MENU mode, select and set current output (4 to 20 mA) and voltage output (±5 V or 1 to 5 V).
(*3) A Calculating Unit (ZX2-CAL) is required.
Model
Item
ZX2-LDA11 ZX2-LDA41
Measurement
period (*1)
Min. 30 µs
Response time 60 µs, 120 µs, 240 µs, 500 µs, 1 ms, 2 ms, 4 ms, 8 ms, 12 ms, 20 ms, 36 ms, 66 ms,
128 ms, 250 ms, 500 ms
Analog output (*2) 4 to 20 mA, Max. load resistance: 300 Ω, ±5 VDC or 1 to 5 VDC,
Output impedance: 100Ω
Judgment outputs
(HIGH/PASS/
LOW: 3 outputs),
error output
NPN open-collector outputs, 30 VDC,
50 mA max.
residual voltage:
1 V max. for load current
10 mA max.,
2 V max. for load current
above 10 mA
PNP open-collector outputs, 30 VDC,
50 mA max.
residual voltage:
1 V max. for load current
10 mA max.,
2 V max. for load current
above 10 mA
Laser OFF input,
zero reset input,
timing input,
reset input,
bank input
ON: Short-circuited with 0-V terminal or
1.2 V or less.
OFF:
Open (leakage current: 0.1 mA max.)
ON: Supply voltage short-circuited or
supply voltage within –1.2 V
OFF:
Open (leakage current: 0.1 mA max.)
Functions Smart tuning, scaling, sample hold, peak hold, bottom hold, peak-to-peak hold,
self-peak hold, self-bottom hold, average hold, zero reset, On-delay timer, OFF-delay
timer, keep/clamp switch, (A-B) calculations (*3), thickness calculation (*3), mutual
interference prevention (*3), laser deterioration detection, bank function (4 banks)
Indications Judgement indicators: HIGH (orange), PASS (green), LOW (orange),11-segment main
display (red), 11-segment sub-display (orange), laser ON (green), zero reset (green),
ENABLE (green), MENU (green), HIGH threshold (orange), LOW threshold (orange)
Power supply
voltage
10 to 30 VDC, including 10% ripple(p-p)
Power
consumption
3,000 mW max. with power supply voltage of 30 VDC and power supply current of
100 mA max. (with Sensor connected)
Ambient
temperature
Operating: 0 to +50°C, Storage: -15 to +70°C (with no icing or condensation)
Ambient humidity Operating and storage: 35% to 85% (with no condensation)
Dielectic strength 1,000 VAC, 50/60 Hz for 1 min.
Vibration resistance
(destruction)
10 to 150 Hz, 0.7–mm double amplitude, 80 min. each in X, Y, and Z directions
Shock resistance
(destruction)
300 m/s
2
3 times each in six directions (up/down, left/right, forward/backward)
Degree of
protection
IEC60529, IP40
Connection method Prewired (standard cable length: 2 m)
Weight
(packed state)
Approx. 200 g (unit only: approx. 135 g)
Materials Case: PBT (polybutylene terephthalate), Cover: Polycarbonate,
Display: Acrylic resin, Buttons: Polyacetal, Cable: PVC
Accessories Instruction sheet
