Omron ZX2 Series User Manual

Specifications and Dimensions
114
ZX2 User’s Manual
INTRODUCTION
MAIN
APPLICATIONS
& SETTING
METHODS
SPECIFI-
CATIONS
INDEX
SETTING
TRANSITION
CHARTS
DETAILED
SETTINGS
FLOW OF
OPERATION
CONTENTS
PREPARATION
FOR
MEASUREMENT
BASIC
SETUP
TROUBLE-
SHOOTING
Height
Double
Sheet
Detection
Positioning
Eccentricity
and Surface
Deflection
Steps
and
Warpage
Thickness
Specifications and Dimensions
Amplifier Units
ZX2-LDA11/LDA41
15.4
16.9
72
6.2
*2
4.2
38.4
*1
16.66.1
20.7 36.8
9.6
34.2
47.6
10.9
18
11.7
30
50 mm
(cover open, 84.6)
Vinyl insulated round cable,
5.2 dia., 11 conductors
(Conductor cross-section 0.09 mm
2
/
Insulator diameter: 0.7 mm)
Standard length: 2 m
*1 Max. height when cover is open: 56
*2 Min. length when connected: 50
(Unit: mm)
