125
Front Panel Rear Panel Remote
Contents
Connections
Playback
Setup
Tuner
Poor reception or much noise
Recheck the antenna connection.
Move the antenna away from the speaker cord or power cord.
Move the unit away from your TV or PC.
Passing cars or airplanes in the vicinity can cause interference.
If radio waves are blocked by concrete walls, etc., radio reception may be poor.
Change the reception mode to mono.
Operating the remote controller during AM reception may cause noise.
FM reception may be clearer if you use the antenna jack on the wall used for the TV.
( p38)
BLUETOOTH function
Unplug and plug the power cord of the unit, or turn o󰀨 and on the BLUETOOTH-enabled device. Restart of the BLUETOOTH-enabled device may
be e󰀨ective.
BLUETOOTH-enabled devices must support the A2DP prole.
Because a radio wave interference will occur, this unit may not be used near devices such as a microwave oven or cordless phone which use the
radio wave in the 2.4 GHz range.
A metallic object near the unit can a󰀨ect on the radio wave, and BLUETOOTH connection may not be possible.
Check the following if the problem persists after you have conrmed the above.
Cannot connect with this unit
Check if the BLUETOOTH function of the BLUETOOTH-enabled device is enabled. ( p104)
Music playback is unavailable on the unit even after successful BLUETOOTH connection
When the audio volume of your BLUETOOTH-enabled device is set low, the audio may not be played back. Turn up the volume of the
BLUETOOTH-enabled device.
Depending on the BLUETOOTH-enabled device, the Send/Receive selector switch may be equipped. Select Send mode.
Depending on the characteristics or specications of the BLUETOOTH-enabled device, music may not be played back on this unit.
Sound is interrupted
There may a problem with the BLUETOOTH-enabled device. Check the information on a web page.
The audio quality is poor after connection with a BLUETOOTH-enabled device
The BLUETOOTH reception is poor. Move the BLUETOOTH-enabled device closer to the unit, or remove any obstacle between the
BLUETOOTH-enabled device and this unit.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Onkyo TX-NR686 and is the answer not in the manual?

Onkyo TX-NR686 Specifications

General IconGeneral
Receiver typeSurround
Audio output channels7.2 channels
Total Harmonic Distortion (THD)1 %
Power output per channel (1KHz@6 Ohm)165 W
Power output per channel (20-20KHz@8 Ohm)- W
HDMI in7
Digital audio coaxial in1
Component video (YPbPr/YCbCr) in2
Line-outYes
Connectivity technologyWireless
Speakers connectivity type-
Bluetooth version4.1
Bluetooth profilesA2DP, AVRCP
AM band range522 - 1710 kHz
FM band range57.5 - 108 MHz
Supported radio bandsAM, FM
Preset stations quantity40
Optical drive includedNo
Supported video modes2160p
Supported graphics resolutions3840 x 2160
HDCP version2.2
Product colorSilver
Audio decodersDTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital 5.1, Dolby TrueHD
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.15 W
Power consumption (typical)570 W
Package weight12500 g
Package depth450 mm
Package width539 mm
Package height260 mm
Weight and Dimensions IconWeight and Dimensions
Depth379.5 mm
Width435 mm
Height173.5 mm
Weight10000 g
