When FM broadcasts reception is poor: Perform the procedure for "Tuning
Manually” ( p61). Note that if you tune manually, the reception for FM
broadcasts will be monaural rather than stereo, irrespective of the sensitivity of
the reception.
Tuning Manually
Note that if you tune manually, the reception for FM broadcasts will be monaural
rather than stereo, irrespective of the sensitivity of the reception.
1. Press TUNER repeatedly to select either "AM" or "FM".
2. Press MODE to display "TunMode: Manual" on the display.
3. While pressing the cursors / , select the desired radio station.
Each time you press the cursors / , the frequency changes by 1 step.
If the button is held down, the frequency changes continuously, and if the
button is released, the frequency stops changing.
Frequency step setting
Press , and using the cursors and ENTER, select “7. Miscellaneous” - “Tuner” -
“AM/FM Frequency Step” or “AM Frequency Step”, and then select the frequency
step for your area. For Taiwanese models, the default value is "10 kHz / 0.2 MHz"
at the time of purchase. Please change it to "9 kHz / 0.05 MHz". Note that when
this setting is changed, all radio presets are deleted.
Presetting a Radio Station ( p62)
