Onkyo TX-NR686 User Manual

75
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
Selectable listening modes
You can select a variety of listening modes
according to the audio format of the signal to be
input.
• List of listening modes selectable with the
MOVIE/TV button ( p75)
• List of listening modes selectable with the MUSIC
button ( p78)
• List of listening modes selectable with the GAME
button ( p82)
• Selectable listening modes when headphones
are connected are Pure Audio, Mono, Direct, and
Stereo only.
 MOVIE/TV button
Input Format Listening Mode
Analog Direct
Mono
DSur
DTS Neural:X
THX Cinema
*1
TV Logic
*2
AllCh Stereo
*3
Full Mono
*3
T-D
*1
Surround speakers need to be installed.
*2
Surround speakers or height speakers need to be installed.
*3
A center speaker, surround speakers, or height speakers need to be
installed.
Input Format Listening Mode
PCM
Music les (except DSD/
Dolby TrueHD)
Direct
Mono
DSur
DTS Neural:X
THX Cinema
*1
TV Logic
*2
AllCh Stereo
*3
Full Mono
*3
T-D
*1
Surround speakers need to be installed.
*2
Surround speakers or height speakers need to be installed.
*3
A center speaker, surround speakers, or height speakers need to be
installed.
Input Format Listening Mode
Multich PCM Direct
Multich
*1
DSur
DTS Neural:X
THX Cinema
*2
THX Sel Cin
*3
TV Logic
*4
AllCh Stereo
*5
Full Mono
*5
T-D
*1
A center speaker or surround speakers need to be installed.
*2
Surround speakers need to be installed.
*3
Surround back speakers need to be installed. Can be selected when the
input format is 5.1 ch.
*4
Surround speakers or height speakers need to be installed.
*5
A center speaker, surround speakers, or height speakers need to be
installed.

Onkyo TX-NR686 Specifications

General

Receiver type	Surround
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	7
Digital audio coaxial in	1
Component video (YPbPr/YCbCr) in	2
Line-out	Yes
Connectivity technology	Wireless
Speakers connectivity type	-
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
AM band range	522 - 1710 kHz
FM band range	57.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Optical drive included	No
Supported video modes	2160p
Supported graphics resolutions	3840 x 2160
HDCP version	2.2
Product color	Silver
Audio decoders	DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital 5.1, Dolby TrueHD
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	570 W
Package weight	12500 g
Package depth	450 mm
Package width	539 mm
Package height	260 mm

Weight and Dimensions

Depth	379.5 mm
Width	435 mm
Height	173.5 mm
Weight	10000 g
