5. Volume
Change the Volume settings.
Setting Item Default Value Setting Details
Volume Display Absolute Switch the volume display between the absolute
value and relative value. The absolute value 82 is
equivalent to the relative value 0dB.
"Absolute": Absolute value such as "1" and "99"
"Relative": Relative value such as "-81dB" and
"+18dB"
• If the absolute value is set to 82, "82Ref"
appears on the display.
Mute Level -∞dB Set the volume lowered from the listening volume
when muting is on. Select a value from "-∞dB",
"-40dB" and "-20dB".
Maximum Volume O Set the maximum value to prevent the volume
from becoming too loud. Select a value from "O",
and "50" to "99". (When "Volume Display" is set to
"Absolute")
Power On Volume Last Set the volume level of when the power is turned
on. Select a value from "Last" (Volume level
before entering standby mode), "Min", "1" to "99"
and "Max". (When "Volume Display" is set to
"Absolute")
• You cannot set a higher value than that of
"Maximum Volume".
Headphone Level 0 dB Adjust the output level of headphones. Select a
value between "-12 dB" and "+12 dB".
4. Source
1. IntelliVolume
Adjust the volume level when there are dierences in volume level among
multiple devices connected to this unit. Select the input selector to make the
setting.
Setting Item Default Value Setting Details
IntelliVolume 0 dB Select a value between "-12 dB" and "+12 dB".
Set a negative value if the volume of the target
device is larger than the others and a positive
value if smaller. To check the audio, play back the
connected device.
• This function does not work in Zone 2.
2. Name Edit
Set an easy name for each input. The set name appears on the main unit’s
display. Select the input selector to make the setting.
Setting Item Default Value Setting Details
Name Edit Input name 1. Select a character or symbol with the cursors,
and press ENTER.
Repeat this operation to input up to 10
characters.
"A/a": Switches between upper and lower cases.
(Pressing MODE on the remote controller also
toggles between upper and lower cases)
"←" "→": Moves the cursor in the arrow direction.
“ ”: Removes a character on the left of the
cursor.
“ ”: Enters a space.
• Pressing CLEAR on the remote controller will
remove all the input characters.
2. After inputting, select "OK" with the cursors, and
press ENTER.
The input name will be saved.
• To name a preset radio station, press TUNER on the remote controller, select AM/FM,
and select the preset number.
