Panasonic Lumix DC-BS1H User Manual

- 147 -- 147 -
8. Connections with External Devices - XLR Microphone Adaptor (Optional)
XLR Microphone Adaptor (Optional)
By attaching an XLR Microphone Adaptor (DMW-XLR1: optional) to the camera, you can use a commercially available XLR
microphone to enable the recording of superior-quality high-res/stereo audio.
A
B
A
Hot shoe
B
Commercially available XLR microphone
Preparation:
●
Turn off the camera, and remove the hot shoe cover. ( 146 / Removing the Hot Shoe Cover)
1 Attach the XLR Microphone Adaptor to the hot shoe.
2 Turn the camera on.
●
Press and hold the camera ON/OFF button for more than one second.
3 Select [XLR Mic Adaptor Setting].
●
[MENU/SET] [ ] [ ] [XLR Mic Adaptor Setting]
[96kHz/24bit]
Records high resolution audio at 96 kHz/24-bit.
●
Only available when [Rec. File Format] is set to [MOV].
●
[Sound Output (SDI)] is set to [OFF].
[48kHz/24bit]
Records high-quality audio at 48 kHz/24-bit.
●
Only available when [Rec. File Format] is set to [MOV].
[48kHz/16bit] Records standard-quality audio at 48 kHz/16-bit.
[OFF] Records audio using the built-in microphone of the camera.

Panasonic Lumix DC-BS1H Specifications

General

Megapixel	24.2 MP
Camera type	MILC Body
Sensor type	CMOS
Sensor format	Full-frame
Image stabilizer	No
Total megapixels	25.28 MP
Image sensor size	- \
Image formats supported	JPEG
Supported aspect ratios	3:2
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	35.6 x 23.8 mm
Still image resolution(s)	6000x4000, 4272x2848, 3024x2016, 3888x2592, 2784x1856, 1968x1312
Scene modes	-
White balance	Auto, Cloudy, Custom modes, Incandescent, Manual, Shade
Self-timer delay	- s
Tripod mounting supported	Yes
Product color	Black
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Quantity per pack	1 pc(s)
Battery voltage	- V
Number of batteries supported	1
Light metering	Centre-weighted, Evaluative (Multi-pattern), Highlight-weighted, Spot
ISO sensitivity	50, 100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, 51200, 102400, 204800
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	204800
ISO sensitivity (min)	50
Light exposure control	Program AE
Light exposure correction	± 5EV (1/2EV; 1/3EV step)
Number of measurement zones	1728
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	1 s
HD type	6K Ultra HD
Video formats supported	MOV, MP4
Maximum video resolution	5952 x 3968 pixels
Audio system	stereo
Compatible memory cards	SD, SDHC, SDXC
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
HDMI connector type	Full-size
Headphone connectivity	3.5 mm
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2

Weight and Dimensions

Depth	78.8 mm
Width	93 mm
Weight	585 g
