Panasonic Lumix DC-BS1H User Manual

- 3 -- 3 -
Contents
Contents
About Operating Instructions 2
1. Introduction 6
Before Use...........................................................................6
Standard Accessories ........................................................ 8
Lenses That Can Be Used .................................................9
Memory Cards That Can Be Used ...................................10
Names of Parts ................................................................. 11
2. Getting Started 16
Power supply ....................................................................16
Supplying power with an AC adaptor ..............................16
Supplying power from a PoE+ power supply ..................17
Turning the camera on ....................................................18
Turning the camera off ....................................................18
Power Indications ............................................................19
Attaching a Lens ...............................................................20
Connecting the external monitor ....................................22
Connecting to the external monitor .................................22
Attaching the Cable Lock Band .......................................23
Inserting Cards (Optional) ...............................................25
Inserting / removing the card...........................................25
Formatting Cards (Initialization) ......................................27
[Folder / File Settings] .....................................................28
[Double Card Slot Function] ............................................ 29
Setting the Clock
(When Turning On for the First Time) ............................. 30
Clock Set .........................................................................30
Time zone .......................................................................32
3. Basic Operations 33
Camera Setting Operations .............................................33
Display Settings................................................................34
Information Display (HDMI/SDI) ......................................34
Output destination screen display ................................... 35
Switching the Display Information ................................... 36
Control Panel ....................................................................38
Quick Menu .......................................................................39
Menu Operation Methods ................................................41
Menu operation ...............................................................41
[Reset] .............................................................................45
4. Recording Videos 46
Recording Videos .............................................................46
Recording Videos ............................................................ 46
[Exposure Mode] ............................................................. 48
Recording Settings For Video .........................................50
[System Frequency] ........................................................50
[Rec. File Format]............................................................50
[Rec Quality]....................................................................51
[Image Area of Video] ......................................................60
Time Code .........................................................................61
Setting the Time Code.....................................................61
Preparations for Time Code Synchronization..................63
Synchronize the Time Code of the External Device
with That of the Camera (TC OUT) .................................64
Synchronize the Time Code of the Camera
with That of the External Device (TC IN) .........................65
Genlock settings...............................................................66
Input a sync signal ..........................................................66
Horizontal phase adjustment...........................................68

Panasonic Lumix DC-BS1H Specifications

General

Megapixel	24.2 MP
Camera type	MILC Body
Sensor type	CMOS
Sensor format	Full-frame
Image stabilizer	No
Total megapixels	25.28 MP
Image sensor size	- \
Image formats supported	JPEG
Supported aspect ratios	3:2
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	35.6 x 23.8 mm
Still image resolution(s)	6000x4000, 4272x2848, 3024x2016, 3888x2592, 2784x1856, 1968x1312
Scene modes	-
White balance	Auto, Cloudy, Custom modes, Incandescent, Manual, Shade
Self-timer delay	- s
Tripod mounting supported	Yes
Product color	Black
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Quantity per pack	1 pc(s)
Battery voltage	- V
Number of batteries supported	1
Light metering	Centre-weighted, Evaluative (Multi-pattern), Highlight-weighted, Spot
ISO sensitivity	50, 100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, 51200, 102400, 204800
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	204800
ISO sensitivity (min)	50
Light exposure control	Program AE
Light exposure correction	± 5EV (1/2EV; 1/3EV step)
Number of measurement zones	1728
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	1 s
HD type	6K Ultra HD
Video formats supported	MOV, MP4
Maximum video resolution	5952 x 3968 pixels
Audio system	stereo
Compatible memory cards	SD, SDHC, SDXC
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
HDMI connector type	Full-size
Headphone connectivity	3.5 mm
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2

Weight and Dimensions

Depth	78.8 mm
Width	93 mm
Weight	585 g
