Panasonic Lumix DC-BS1H User Manual

- 17 -- 17 -
2. Getting Started - Power supply
●
Do not use any other AC adaptors except the supplied one. This may cause malfunction.
●
Do not use any other AC cables/AC mains leads except the supplied one. This may cause malfunction.
●
Turn off the camera before connecting or disconnecting the power plug.
●
Do not leave any metal items (such as clips) near the contact areas of the power plug. Otherwise, a fire and/or electric
shocks may be caused by short-circuiting or the resulting heat generated.
●
Do not use the AC adaptor and AC cable/AC mains lead with other devices. This may cause malfunction.
●
If there is a power outage or other problems with the electrical outlet, please reconnect the power plug.
●
Power is being consumed even if the camera is turned off. When the camera will not be used for a long time, remove the
power plug from the electrical outlet in order to save power.
Supplying power from a PoE+ power supply
This camera is PoE+ (IEEE 802.3at compliant) compatible. Connect the camera to a PoE+ compatible switching hub or PoE+
compatible injector to supply power (power supply).
C
A
B
A
PoE+ compatible LAN cable (commercially available)
B
PoE+ compatible switching hub (commercially available)
C
Power plug
1 Connect the [LAN] terminal of the camera and the PoE+ compatible switching hub
with a PoE+ compatible LAN cable.
●
For the cable that connects to the LAN terminal, use the one below.
– LAN cable (STP (Shielded Twisted Pair), category 5e or above, maximum 100 m (328 feet))
●
Use a PoE+ (IEEE 802.3at compliant) compatible switching hub or power supplying device. *
1
(Not all PoE+ (IEEE 802.3at compliant) compatible device operations are guaranteed.)
*
1
Make sure it complies with the safety standards IEC 60950-1 or IEC 62368-1. If you are uncertain on whether or not it
complies with the safety standards, please contact the manufacturer of the switching hub or power supplying device.
●
You cannot use a PoE (IEEE 802.3af compliant) switching hub or power supplying device.
●
After turning the camera on, when the device or cable used is determined PoE+ incompatible by the camera, the camera
automatically turns off. (Determining may take approximately 3 minutes.)
●
The camera’s Wi-Fi connection, Bluetooth connection, and USB connection cannot be used while supplying power with
PoE+.
●
If you connect a PC to a switching hub that supplies power to the camera with PoE+ via a LAN cable, you can remotely
control the camera with the software “LUMIX Tether” while supplying power to the camera with PoE+.

Panasonic Lumix DC-BS1H Specifications

General

Megapixel	24.2 MP
Camera type	MILC Body
Sensor type	CMOS
Sensor format	Full-frame
Image stabilizer	No
Total megapixels	25.28 MP
Image sensor size	- \
Image formats supported	JPEG
Supported aspect ratios	3:2
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	35.6 x 23.8 mm
Still image resolution(s)	6000x4000, 4272x2848, 3024x2016, 3888x2592, 2784x1856, 1968x1312
Scene modes	-
White balance	Auto, Cloudy, Custom modes, Incandescent, Manual, Shade
Self-timer delay	- s
Tripod mounting supported	Yes
Product color	Black
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Quantity per pack	1 pc(s)
Battery voltage	- V
Number of batteries supported	1
Light metering	Centre-weighted, Evaluative (Multi-pattern), Highlight-weighted, Spot
ISO sensitivity	50, 100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, 51200, 102400, 204800
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	204800
ISO sensitivity (min)	50
Light exposure control	Program AE
Light exposure correction	± 5EV (1/2EV; 1/3EV step)
Number of measurement zones	1728
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	1 s
HD type	6K Ultra HD
Video formats supported	MOV, MP4
Maximum video resolution	5952 x 3968 pixels
Audio system	stereo
Compatible memory cards	SD, SDHC, SDXC
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
HDMI connector type	Full-size
Headphone connectivity	3.5 mm
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2

Weight and Dimensions

Depth	78.8 mm
Width	93 mm
Weight	585 g
