Magellan & Spectra SP • Programming Guide
Version 4.7/4.92/5.12
Programmable Output Programming | 21
Description of MG/SP Events
Table 12: List of events for MG/SP control panels
Event Group Event Group Description Sub-group Sub-group Description
00 Zone OK 01 to 32 Zone number
01 Zone open 99 Any zone number
02 Partition status
00 to 01 -
02 Silent alarm
03 Buzzer alarm
04 Steady alarm
05 Pulsed alarm
06 Strobe
07 Alarm stopped
08 Squawk ON (partition 1only)
09 Squawk OFF (partition 1 only)
10 Ground start (partition 1 only)
11 Disarm partition
12 Arm partition
13 Entry delay started
14 Exit delay started
15 Pre-alarm delay
16 Report confirmation
99 Any partition status event
03 Bell status (partition 1 only)
00 Bell OFF
01 Bell ON
02 Bell squawk arm
03 Bell squawk disarm
99 Any bell status event
06 Non-reportable event
00 Telephone line trouble
01 CLEAR + ENTER, or was pressed for 3 secs. (partition 1 only)
02 -
03 Arm in Stay mode
04 Arm in Sleep mode
05 Arm in Force mode
06 Full arm when armed in Stay mode
07 PC fail to communicate (partition 1 only)
08 Utility key 1 pressed (keys 1 and 2; partition 1 only)
09 Utility key 2 pressed (keys 4 and 5; partition 1 only)
10 Utility key 3 pressed (keys 7 and 8; partition 1 only)
11 Utility key 4 pressed (keys 2 and 3; partition 1 only)
12 Utility key 5 pressed (keys 5 and 6; partition 1 only)
13 Utility key 6 pressed (keys 8 and 9; partition 1 only)
14 Tamper generated alarm
15 Supervision loss generated alarm
16 -
17 -
18 -
19 -
20 Full arm when armed in Sleep mode
21 Firmware upgrade (partition 1 only; non-PGM event)
22 -
23 StayD mode activated
24 StayD mode deactivated
