Trouble Display
The following section provides information on the different troubles associated with your MG/SP control panel. To view the trouble display, press TBL on your
MG/SP keypad. Table 55 outlines the troubles appearing in the main menu and their corresponding sub-menu troubles. To view the sub-menu troubles, press the
trouble’s respective key in the main menu.
NOTE: Keypads can be programmed to emit a beep every five seconds, whenever a new trouble condition has occurred. Press
TBL to stop the beeping.
Table 55: Description of troubles for MG/SP control panels
Key Main Menu Trouble Key Sub-menu Trouble
1 Wireless zone low battery 1 to 32 Zones in low battery
2 Power trouble
1 Low/no battery on the control panel
2AC failure on control panel
3 Auxiliary overload on control panel
4 Wireless keypad AC failure
5 Wireless keypad battery failure
6 Wireless repeater AC failure
7 Wireless repeater battery failure
8 Wireless siren AC failure
9 Wireless siren battery failure
10 Remote low battery (press [0] to view which remote)
3Bell trouble
1 Bell disconnected on control panel
2 Bell overload on control panel
