28 | Programmable Output Programming
Magellan & Spectra SP • Programming Guide
PGM Options
1
If a PGM delay is programmed (OFF option), the deactivation event can be used as a second activation event.
Section [277] for SP65
NOTE: Section [277] only applies to the SP65 system.
Table 13: Description of PGM options
Option Description
PGM 1 [261] PGM 2 [262] PGM 3 [263] PGM 4 [264] PGM 5 [265] PGM 6 [266] PGM 7 [267] PGM 8 [268]
OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON
1 PGM base time (OFF = sec., ON = min.) 















2 PGM state (OFF = N.O.; ON = N.C.) 















3 PGM supervision (not applicable to SP4000)
















4
PGM activation mode
(OFF = steady; ON = pulse)
















5 PGM pulse once every 30 seconds, if armed 















6 PGM pulse on any alarm 















7
PGM pulse on any alarm (OFF = partition 1;
ON = partition 2)
















8
Flexible PGM deactivation option
(OFF
1
= PGM delay only, two activation
events; ON = PGM delay or deactivation
event, whichever comes first)
















Option Description
PGM 9 [269] PGM 10 [270] PGM 11 [271] PGM 12 [272] PGM 13 [273] PGM 14 [274] PGM 15 [275] PGM 16 [276]
OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON
1 PGM base time (OFF = sec., ON = min.) 















2 PGM state (OFF = N.O.; ON = N.C.) 















3 PGM supervision (not applicable to SP4000)
















4
PGM activation mode (OFF = steady;
ON = pulse)
















5 PGM pulse once every 30 seconds, if armed 















6 PGM pulse on any alarm 















7
PGM pulse on any alarm (OFF = partition 1;
ON = partition 2)
















8
Flexible PGM deactivation option
(OFF
1
= PGM delay only, two activation
events; ON = PGM delay or deactivation
event, whichever comes first)
















= Default Setting
Table 14: Description of section [277] for SP65
Option Option Type Description
[277]
OFF ON
1
Voltage output
(OFF = negative trigger, 0V;
ON = positive trigger, 12V)
PGM 1 

2PGM 2

3PGM 3

= Default Setting
