TIGHTENING TORQUES
11
Reproduction ou traduction, même partielle, interdite sans autorisation écrite de Peugeot Motocycles
Body panels
Cycle part
Standard
Front mudguard. 0.8 to 1.2 m.daN
Handlebar cover. 0.2 to 0.4 m.daN
Front shield panels. 0.2 to 0.4 m.daN
Rear shield. 0.2 to 0.4 m.daN
Bottom panel. 0.2 to 0.4 m.daN
Floor panel. 0.4 to 0.6 m.daN
Saddle storage compartment. 0.8 to 1.2 m.daN
Rear panels. 0.2 to 0.4 m.daN
Grab handle. 2 to 2.5 m.daN
Rear mudguard. 0.4 to 0.6 m.daN
Front wheel spindle. 6.5 m.daN
Rear wheel bolt. 10 m.daN
Rear wheel spindle nut. 13.5 m.daN
Linkrod to engine pivot. 5.8 m.daN
Linkrod to frame pivot. 5.8 m.daN
Linkrod connecting pin 3.6 m.daN
Linkrod to frame adjustment locknut 10 m.daN
Linkrod to frame mounting bolt 6.8 m.daN
Shock absorber top mount. 4.5 m.daN
Shock absorber bottom mount. 4.5 m.daN
Exhaust to cylinder head mounting nut. 1.8 m.daN
Exhaust to casing mounting bolt. 2.5 m.daN
Exhaust clamp. 1.8 m.daN
Upper cone (in 2 operations). 4/2.2 m.daN
Upper cone locknut. Hand tightened
Steering locknut. 7.5 m.daN
Front brake caliper. 2.5 m.daN
Rear brake caliper. 2.5 m.daN
Front brake disc. 3 m.daN
Rear brake disc. 0.9 m.daN
Handle bar. 4 m.daN
Nut and bolt 5 mm diameter. 0.6 m.daN
Nut and bolt 6 mm diameter. 1 m.daN
Nut and bolt 8 mm diameter. 2.2 m.daN
Nut and bolt 10 mm diameter. 3.5 m.daN
Nut and bolt 12 mm diameter. 5.5 m.daN
