PEUGEOT Geopolis 250 Repair Manual

BODY PANELS
19
Reproduction ou traduction, même partielle, interdite sans autorisation écrite de Peugeot Motocycles
- Remove the rear body cover. (4 screw).
- Remove the access door. (1 screw).
- Remove the 2 screws that secure the
footrest. (2)
- Remove the rear cover 3 fixing screws. (3)
- Unclip the support (A) and remove the side
panel together with the footrest.
 Removal of the tank covers
Procedure 3.
- Remove the saddle. (2 screw).
- Remove the battery cover. (1)
- Open the tank filler cap door.
- Remove the upper fairing. (2)
A
2
3
3
1
2

PEUGEOT Geopolis 250 Specifications

General

Displacement	244.3 cc
Cooling System	Liquid cooled
Transmission	Automatic CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual shock absorbers
Engine Type	Single cylinder, 4-stroke
Front Tire	120/70-15
Power	22.5 hp
