PEUGEOT Geopolis 250 Repair Manual

MISCELLANEOUS OPERATIONS
34
Reproduction ou traduction, même partielle, interdite sans autorisation écrite de Peugeot Motocycles
 Removal of the fuel pump
- Remove the tank cover panel. See:
Procedure 3. page 19.
- Carry out the procedure for lowering the
pressure in the fuel system. See:
Procedure 7. page 33.
- Disconnect the fuel pump.
- Disconnect the 2 fuel pipes.
- Loosen by hand the pump locking ring. (1)
- Remove the fuel pump.
 Removal of the fuel gauge
- Remove the tank cover panel. See:
Procedure 3. page 19.
- Disconnect the fuel gauge.
- Using tool P/N 756715, remove the fuel
gauge
Note: Modify the tool P/N 756715 as shown
in the sketch in order to use it with
the Geopolis.
1
756715

PEUGEOT Geopolis 250 Specifications

General

Displacement	244.3 cc
Cooling System	Liquid cooled
Transmission	Automatic CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual shock absorbers
Engine Type	Single cylinder, 4-stroke
Front Tire	120/70-15
Power	22.5 hp
