PEUGEOT Geopolis 250 Repair Manual

BODY PANELS
23
Reproduction ou traduction, même partielle, interdite sans autorisation écrite de Peugeot Motocycles
 Removal of the instrument cluster
- Remove the handlebar front cover.
(2 screw).
- Remove the screen. (4 screw).
- Remove the handlebar rear cover and
instrument cluster assembly. (7 screw).
- Disconnect the instrument cluster.
 Removal of the battery holder
Procedure 6.
- Remove the tank cover panel. See:
Procedure 3. page 19.
- Remove the storage compartment. See:
Procedure 1. page 18
- Disconnect and remove the battery.
- Unclip from the battery holder:
• The fuses. (1)
• The relays. (2)
- Remove the battery bracket. (3 screw).
2
1

PEUGEOT Geopolis 250 Specifications

General

Displacement	244.3 cc
Cooling System	Liquid cooled
Transmission	Automatic CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual shock absorbers
Engine Type	Single cylinder, 4-stroke
Front Tire	120/70-15
Power	22.5 hp
