PEUGEOT Geopolis 250 Repair Manual

BODY PANELS
18
Reproduction ou traduction, même partielle, interdite sans autorisation écrite de Peugeot Motocycles
 Removal of the storage compartment
Procedure 1.
- Remove the storage compartment.
(2 screws and 2 nuts).
 Removal of a RH or LH side cover
Procedure 2.
- Remove the storage compartment. See:
Procedure 1. page 18.
- Remove the luggage carrier trim. (1)
- Remove the luggage carrier. (2 screws and
1 nut).
- Remove the splash guard. (4 screw).
- Disconnect the license plate light.
1

PEUGEOT Geopolis 250 Specifications

General

Displacement	244.3 cc
Cooling System	Liquid cooled
Transmission	Automatic CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual shock absorbers
Engine Type	Single cylinder, 4-stroke
Front Tire	120/70-15
Power	22.5 hp
