01_12
Start-up button (01_12)
To start the engine, pull either brake lever and then press the starter button «R».
WARNING
THE VEHICLE WILL START BUT WILL IDLE IF THE RIDER IS NOT SEATED ON
THE SADDLE IN RIDING POSITION.
01_13
Engine stop button (01_13)
The engine can be started when the emergency stop switch «N» is set to «1» RUN;
if the emergency cut-off switch «N» is set to «0» OFF, the engine cannot be started
or it shuts off if already running.
17
