01_23
Power supply socket (01_23)
There is a plug socket «D» inside the rear case.
The plug socket may be used for external consumers (mobile phone, inspection light,
etc.).
CAUTION
PROLONGED USE OF THE PLUG SOCKET MAY RESULT IN PARTIAL DIS-
CHARGE OF THE BATTERY
Electric characteristic
Plug socket
12 V - 180 W MAX
01_24
The saddle (01_24, 01_25, 01_26)
The saddle is supplied with a protection cover which may be used in case of rain.
Lift the saddle and extract the cover from its housing, then extend it over the whole
length of the saddle, starting from the front-end; do not over stretch the cover to avoid
tearing the material; close the saddle.
CAUTION
DO NOT USE THE VEHICLE WITHOUT THE PROTECTION COVER.
24
