03_07
03_08
Spark plug dismantlement (03_07, 03_08)
Proceed as follows:
1.Remove the access cover over the spark plug on the right-hand side of the scooter,
reach the spark plug and slide it off with your hand;
2.Disconnect spark plug HV wire cap «A»;
3. Unscrew the spark plug using the wrench supplied;
4.Upon refitting, place the spark plug into the hole at the required angle and tighten it
by hand.
5.Use the wrench only to tighten it;
6.Push cap «A » fully over the spark plug.
N.B.
USING SPARK PLUGS OTHER THAN THE INDICATED TYPE OR SHIELDLESS
SPARK PLUG CAPS CAN CAUSE ELECTRICAL SYSTEM FAILURES.
WARNING
THE SPARK PLUG MUST BE REMOVED WHEN THE ENGINE IS COLD. CHECK
THE SPARK PLUG AS INDICATED IN THE SCHEDULED MAINTENANCE TABLE.
USING NON-COMPLYING ELECTRONIC CENTRAL UNITS AND ELECTRONIC
IGNITIONS OR SPARK PLUGS OTHER THAN THOSE PRESCRIBED MAY SERI-
OUSLY DAMAGE THE ENGINE. IF THE SPARK PLUG IS REMOVED AFTER A
FLOODED ENGINE (EXCESSIVE FUEL EXPULSION IN THE «SAFE RIDING»
SECTION), KEEP THE TUBE CONNECTED TO THE SPARK PLUG AND THE
LATTER IN CONTACT WITH A GROUND POINT FAR FROM THE SPARK PLUG
HOLE ITSELF IN ORDER TO AVOID THE EXPELLED FUEL FROM CATCHING
FIRE.
Characteristic
Spark plug
65
