01_28
01_29
Opening the saddle to access the helmet compartment in an
emergency (01_28, 01_29)
If the remote control battery or the vehicle battery is discharged, follow these steps to
open the saddle:
1. Open the rear compartment with the key switch
2. Remove the rubber cover
3. Softly press with your hand on the point shown in the photo and in the sense
indicated by the arrow inside the helmet compartment until the saddle closing
device springs
01_30
Opening of top box (01_30)
When the key is set to «ON» or «OFF» the rear compartment can be opened by
pressing button «U» on the handlebar.
WARNING
OBJECTS INAPPROPRIATELY PLACED INSIDE THE REAR CASE MAY CAUSE
THE DOOR TO DEFORM AND MAY PREVENT THE COURTESY LIGHT FROM
26
