CAUTION
USING OILS OTHER THAN THOSE RECOMMENDED CAN SHORTEN THE LIFE
OF THE ENGINE.
Recommended products
AGIP CITY HI TEC 4T
Engine oil
SAE 5W-40, API SL, ACEA A3, JASO MA Synthetic oil
03_04
Hub oil level (03_04, 03_05)
Check the oil in the rear hub. To check the rear hub oil level, proceed as follows:
1. Rest the vehicle on its centre stand on an even surface.
2. Unscrew the hub oil dipstick «A», dry it with a clean cloth and then reinsert it,
screwing it fully into place.
3. Pull out the dipstick to check that the hub oil level is slightly over the notch indicated
by the arrow in the figure. This is the correct level and it must remain constant at all
times.
4. Screw the oil dipstick back into place completely.
N.B.
THE NOTCHES ON THE HUB OIL LEVEL DIPSTICK, EXCEPT THE ONE INDI-
CATING THE MAX LEVEL, REFER TO OTHER MODELS BY THE MANUFACTUR-
ER AND HAVE NO SPECIFIC FUNCTION FOR THIS MODEL.
61
