Specifications
General
Rated power source ............... 14.4 V DC
(allowable voltage range:
10.8 V to 15.1 V DC)
Grounding system ................... Negative type
Maximum current consumption
..................................................... 10.0 A
Dimensions (W × H × D):
DIN
Chassis ......................................... 178 mm × 100 mm ×
157 mm
Nose ............................................... 188 mm × 118 mm ×
26 mm
(AVH-X5600BT)
Nose ............................................... 188 mm × 118 mm ×
17 mm
(AVH-X3600DAB/AVH-X2600BT/AVH-X1600DVD)
D
Chassis ......................................... 178 mm × 100 mm ×
165 mm
Nose ............................................... 171 mm × 97 mm × 18 mm
(AVH-X5600BT)
Nose ............................................... 171 mm × 97 mm × 9 mm
(AVH-X3600DAB/AVH-X2600BT/AVH-X1600DVD)
Weight .......................................... 2.0 kg
(AVH-X5600BT)
Weight .......................................... 1.7 kg
(AVH-X3600DAB/AVH-X2600BT/AVH-X1600DVD)
Display
Screen size/aspect ratio ....... 6.95 inch wide/16:9
(effective display area:
156.6 mm × 81.6 mm)
(AVH-X5600BT)
Screen size/aspect ratio ....... 6.1 inch wide/16:9
(effective display area:
136.2 mm × 72.0 mm)
(AVH-X3600DAB/AVH-X2600BT/AVH-X1600DVD)
Pixels ............................................. 1 152 000 (2 400 × 480)
Display method ........................ TFT active matrix, driving
type
Color system .............................. NTSC/PAL/PAL-M/PAL-N/
SECAM compatible
Durable temperature range (power off)
..................................................... –20 °C to +80 °C
Audio
Maximum power output ....... 50 W × 4
70 W × 1/2 W (for subwoo-
fer)
Continuous power output ... 22 W × 4 (50 Hz to
15 000 Hz, 5 % THD,
4 W load, both channels dri-
ven)
Load impedance ...................... 4 W (4 W to 8 W (2 W for 1 ch)
allowable)
Preout maximum output level
..................................................... 4.0 V
(AVH-X5600BT)
Preout maximum output level
..................................................... 2.0 V
(AVH-X3600DAB/AVH-X2600BT/AVH-X1600DVD)
Equalizer (8-Band Graphic Equalizer):
Frequency .................................... 40 Hz/80 Hz/200 Hz/400 Hz/
1 kHz/2.5 kHz/8 kHz/10 kHz
Gain ................................................ ±12 dB
HPF:
Frequency .................................... 50 Hz/63 Hz/80 Hz/100 Hz/
125 Hz
Slope .............................................. –12 dB/oct
Subwoofer (mono):
Frequency .................................... 50 Hz/63 Hz/80 Hz/100 Hz/
125 Hz
Slope .............................................. –18 dB/oct
Gain ................................................ +6 dB to –24 dB
Phase ............................................ Normal/Reverse
Bass boost:
Gain ................................................ +12 dB to 0 dB
DVD Player
System .......................................... DVD video, Video CD, CD,
WMA, MP3, AAC, DivX,
MPEG player
Usable discs .............................. DVD video, Video CD, CD,
CD-R/RW, DVD-R/RW/R DL
Region number ........................ 2
Frequency response ............... 5 Hz to 44 000 Hz (with DVD,
at sampling frequency
96 kHz)
Signal-to-noise ratio ............... 96 dB (1 kHz) (IEC-A net-
work) (RCA level)
Output level:
Video .............................................. 1.0 Vp-p/75 W (±0.2 V)
Number of channels .............. 2 (stereo)
MP3 decoding format ........... MPEG-1 & 2 Audio Layer 3
WMA decoding format ......... Ver. 7, 7.1, 8, 9, 10, 11, 12
(2 ch audio)
(Windows Media Player)
AAC decoding format ............ MPEG-4 AAC (iTunes en-
coded only) (.m4a)
(Ver. 10.6 and earlier)
DivX decoding format ............ Home Theater Ver. 3, 4, 5.2,
6 (Except ultra and HD)
(.avi, .divx)
En
98
Appendix
Additional information
