Point Mobile PM260 User Manual

Suffix
Enter Suffix to be sent after the
decoded/received data
Symbologies
Select barcode types you want to read
There is “Enable All” and “Disable All” to enable/disable all symbologies
Tab Section Option Description
Details
Specifies or enable
available detail settings
in symbologies
Enable this code
Tap/enable this checkbox to
enable the selected bar code
type.
Barcode ID
Enter
the desired features you
wish to transmit as bar code ID
Length
Set the minimum and maximum
lengths from the pull-down lists.
If the numbers are the same,
acceptable bar codes will only
be that length. Not all types will
have this option enabled.
Redundancy(N4313
device only)
If you are encountering errors
when reading some bar codes,
you may want to adjust the
redundancy count. Redundancy
adjusts the number of times a
bar code is decoded before
transmission, which may reduce
the number of errors. Note that
the higher the redundancy
count, the longer it will take to
decode the bar code
About
Specifies Barcode engine type, Firmware revision, Decider revision, API revision
Load Factory Default
After modifying the current
settings, if you wish to return to
the factory defaults, tap the
Load Factory Default button.
10. Communication
10.1.
Communication Options
Handy Terminal offers several communication options including Microsoft ActiveSync and wireless
radios.
I/O Connector (Wired Communication)
The mechanical connector on the bottom panel connects the terminal to various Handy
Terminal communication peripherals that connect to a host workstation via USB (1.1 or
higher), thus enabling ActiveSync communication.
For more information, see ActiveSync Communication on paragraph 10.4.
51

Point Mobile PM260 Specifications

General

Brand	Point Mobile
Model	PM260
Category	Handhelds
Language	English
