5.8
9928492 R04 - 2017-2018 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
PVT COVERS AND DUCTING COMPONENTS (HIGH LIFTER)
q
Inlet/Outlet Duct
s
Screw, Inlet Duct
w
Band Clamp
d
Retaining Bracket, Upper Exhaust Hose
e
Upper Intake Hose
f
Inner Cover Seal
r
Upper Exhaust Hose
g
Inner Clutch Cover
t
Middle Intake Hose
h
Guard Plate
y
Lower Intake Hose
j
Inner Clutch Cover Screw (7)
u
Lower Exhaust Hose
k
Outer Cover Seal
i
Outlet Duct
l
Outer Clutch Cover
o
Inlet Duct
1(
Outer Clutch Cover Screw (8)
a
Boot
2)
PVT Drain Screw
PVT SYSTEM
