14.1Waypoints
Awaypointisapositionmarkedonthescreentoindicateasite
oraplacetonavigateto.
Aswellasactingaspositionmarkers,waypointsarealsothe
buildingblocksusedtocreateroutes.
Commonwaypointfunctionsareaccessedusingthewaypoints
menu.ThiscanbeshownatanytimebyselectingWPT.
Waypointdisplayexamples
Waypointsinthechartapplication
Inthechartapplicationbothactiveandinactivewaypointsare
shown.Theactivewaypoint(i.e.theoneyouareheading
towards)hastheboxandsymbolcolorsreversed.
D
117 61-2
1
2
3
ItemDescription
1Inactivewaypoint
2Activewaypoint
3Alternativewaypointsymbols
Bydefault,allwaypointsareindicatedonscreenbyawaypoint
symbol(x).Youcanassigndifferentsymbolsifrequired,or
choosewhichwaypointsareshown.
Waypointsintheradarapplication
Intheradarapplicationbothactiveandinactivewaypointsare
shown.Theactivewaypoint(i.e.theoneyouareheading
towards)hastheboxandsymbolcolorsreversed.
D
117 59-2
Bydefault,allwaypointsareindicatedonscreenbyawaypoint
symbol(x).Youcanassigndifferentsymbolsifrequired,or
choosewhichwaypointsareshown.
Waypointsintheshnderapplication
Waypointsintheshnderapplicationarerepresentedbya
verticallinelabelledWPT .
Showingandhidingwaypointgroups/symbols
Fromthechartorradarapplication:
1.SelectWPT.
2.SelectDisplayWptson:Chart,orDisplayWptson:Radar
dependingontheapplicationyouhaveopen.
3.TheDisplayWaypointslistisdisplayed.
4.SelectChangetoswitchbetweenGroupsandSymbols.
AlistofSymbolsorGroupsisdisplayed.
5.SelecttheGrouporSymbolyouwishtoshow/hidefromthe
list.
SelectingontheSymbol/GroupwillswitchbetweenShow
andHide.
6.RepeatStep5foreachwaypointgrouporsymbolyouwant
toshoworhide.
Thelistofwaypointsandsymbolscanalsobeaccessedfrom
theChartandRadarapplicationsmenu:
•Chartapplication:Menu>MyData>DisplayMyData>
SelectWPTsToDisplay.
•Radarapplication:Menu>Presentation>SelectWPTsTo
Display.
Waypointcontextmenu
Placingthecursoroverawaypointinthechartorradar
applicationsdisplaysacontextmenushowingthewaypoint's
positionaldataandmenuitems.
Thecontextmenuprovidesthefollowingpositionaldataforthe
waypointinrelationtoyourvessel:
•Latitude
•Longitude
•Range
•Bearing
Forinactivewaypointsthefollowingmenuitemsareavailable:
•GotoWaypoint
•FollowFromHere(onlyavailablewhenwaypointispartofa
route.)
•EditWaypoint
•EraseWaypoint
•RemoveWaypoint(onlyavailablewhenwaypointispartofa
route.)
•MoveWaypoint
•Measure
•BuildRoute
•AcquireTarget(onlyavailableifRadaroverlayisswitched
on.)
•Slewthermalcamera(onlyavailablewhenthermalcamera
isconnectedandoperating.)
Foractivewaypointsthefollowingmenuitemsareavailable:
128NewaSeries/NewcSeries/NeweSeries
