4.12NMEA0183connection
NMEA0183devicescanbeconnectedtoNewcSeriesandNew
eSeriesmultifunctiondisplaysusingthepoweranddatacable.
Note:NewaSeriesdoesnotsupportconnectionofNMEA
0183devices.
NMEA0183devicesareconnectedusingthesuppliedpower
anddatacable.
Thedisplayhas2NMEA0183ports:
•Port1:Inputandoutput,4800or38400baudrate.
•Port2:Inputonly,4800or38400baudrate.
Note:Thebaudrateyouwanttouseforeachportinputmust
bespeciedintheSystemSettingsmenu(Homescreen:>
Set-up>SystemSettings>NMEASet-up>NMEAInput
Port).
Note:ForPort1,boththeinputandoutputcommunicateat
thesamebaudrate.Forexample,ifyouhaveoneNMEA
0183deviceconnectedtothedisplay'sPort1INPUT ,and
anotherNMEA0183deviceconnectedtothedisplay'sPort
1OUTPUT ,bothNMEAdevicesmustbeusingthesame
baudrate.
Youcanconnectupto4NMEA0183devicestothedisplay's
NMEA0183OUTPUT(Port1).Youcanconnectatotalof2
NMEA0183devicestothedisplay'sNMEA0183INPUTports.
Ite-
mDevice
Cable
colorPort
Input/
output
Positive
(+)/
negative
(-)
1White1InputPositive
2
Green
1InputNegative
3Yellow1
Output
Positive
4Brown1
Output
Negative
5
Orange/
white
2InputPositive
6
Multifunc-
tiondisplay
Orange/
green
2InputNegative
Ite-
mDevice
Cable
colorPort
Input/
output
Positive
(+)/
negative
(-)
7
**Output
Positive
8
**Output
Negative
9
**
InputPositive
10
NMEA
device
**
InputNegative
11
**Output
Positive
12
NMEA
device
**Output
Negative
Note:*RefertoinstructionsprovidedwithNMEAdevice.
NMEA0183cable
YoucanextendtheNMEA0183wireswithinthesuppliedpower
anddatacable.
Datacableextension
Totallength(max)Cable
Upto5mHighqualitydatacable:
•2xtwistedpairwithoverallshield.
•50to75pF/mcapacitancecore
tocore.
54NewaSeries/NewcSeries/NeweSeries
