8.1Documentvieweroverview
Yourmultifunctiondisplayincludesapdfdocumentviewer.
Thedocumentviewerisavailablefromthehomescreenand
isusedtoviewandsearchpdfdocuments(suchasproduct
handbooks).
D12755-1
1
2
3
1
OpenstheSDcardlebrowser.
2
Openstheusermanualstoredonthemultifunction
display.
3
Openstherelevantlicenseagreementinformation.
Note:Thedocumentviewerdoesnotsupportpassword
protecteddocumentsordocumentscontainingsecurity
certicates.Anerrormessagewillbedisplayedifyoutryto
opensuchdocuments.
D12597-1
1
7
3 42
5
6
1
Currentpagenumber(pagexofy)
2
Find(search)toolbar(onlydisplayedwhensearching
adocument).
Note:ThePrevious,NextandCancelbuttons
areonlyshownontouchonlyproducts.For
non-touchandHybridtouchproductsthephysical
buttonsareused.
3
Currentpdf’slename
4Documentviewermenu
5
Scrollbar
6
On-screenzoomcontrols(Touchscreendisplaysonly)
7
pdfdocumentcontent
Thefollowingoptionsareavailablefromthedocumentviewer
menu:
•OpenFile—Allowsyoutobrowseforapdfdocumenttoopen.
•Gotopage:—Allowsyoutojumptoaspeciedpage
number.
•Find—Allowsyoutosearchthedocumentforaspecied
words.
•FittoHeight—Scalestheopendocumenttottheheightof
theapplicationwindow.
•FittoWidth—Scalestheopendocumenttotthewidthof
theapplicationwindow.
•CloseFile—Closestheopendocument.
Openingtheusermanual
Theproductusermanualisstoredontheinternalmemory.
Fromthehomescreen:
1.SelectDocViewer.
2.SelectUserManual.
Theproductusermanualisopened.
Openingapdfdocument
YoucanopenpdfdocumentsstoredonanSDcardbyfollowing
thestepsbelow.
Note:WhensavingpdfdocumentstoSDcards,ensureyou
donotoverwriteimportantdata.
1.SavetherequiredpdfdocumenttoSDcard.
2.InserttheSDcardintotheSDcardslotofthemultifunction
displayyouwishtoviewthedocumenton.
3.SelectMenu.
4.SelectOpenFile.
Thelebrowserdialogisdisplayed.
5.BrowsetothelocationontheSDcardwhereyousavedthe
documentto.
6.Selectthedocumentyouwanttoview.
Thedocumentwillnowopen.
7.Ifthe‘CannotOpenFile’errormessageisdisplayedthen
selectOktoconrmandthentryopeningthedocument
againorcheckthatthepdfisnotcorruptedorwhetherit
containssecuritywhichisnotsupportedbythedocument
viewerapplication.
Note:Largelesizepdfdocumentsmaytakeawhiletoopen.
Closinganopendocument
EachDocviewerinstanceisseparate,thelastdocumentopened
willautomaticallyopennexttimeyouselectthatinstanceofthe
DocviewerunlessititsclosedusingtheCloseFilemenuoption.
Withadocumentopen
1.SelectMenu.
2.SelectClosele.
ThedocumentiscloseandthemainDocviewerpageis
displayed.
Browsinganopendocument
Ontouchscreendisplaysyoucanbrowsepdfdocumentsas
detailedbelow.
Withapdfdocumentopen:
•Moveyourngeruptoscrolldownthedocument.
•Moveyourngerdowntoscrollupthedocument.
Whenthedocumentwidthisgreaterthanthewidthofthe
applicationwindow,moveyourngerleftorrighttopan
thewidthofthedocument.
Note:Y oucanalsousethescrollbarstonavigatethrough
thedocument.
98NewaSeries/NewcSeries/NeweSeries
