3.7Typicalsystems
Theillustrationsbelowshowexamplesofpossiblesystemcongurations,formoredetailsoncompatibledevicespleaserefertothe
Systemintegrationsection.
Note:Intheexamplesbelowthemultifunctiondisplay(s)couldbeanyofthefollowing:
•NewaSeries
•NewcSeries
•NeweSeries
Example:Basicsystem
SeaTalk
ng
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
SMARTPILOT
D12 24 5-2
1
2
3 4 5
1.RaymarineMultifunctiondisplay.
2.Raymarinenetworkswitch.
3.Raymarineradarscanner.
4.SPXcoursecomputer.
5.SeaTalk
ng
Pilotcontroller.
Note:AnetworkswitchisonlyrequiredifmultipledevicesareconnectedusingSeaTalk
hs
/RayNet.
Example:BasicsystemwithSeaTalkequipment
SeaTalk
ng
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
SMARTPILOT
D12 24 6-2
1 2 3 4 5
6
1.Multifunctiondisplay
2.Networkswitch.
3.Radarscanner.
4.SPXcoursecomputer.
5.SeaTalkpilotcontroller.
6.SeaTalktoSeaTalk
ng
converter.
Note:AnetworkswitchisonlyrequiredifmorethanonedeviceisconnectedusingSeaT alk
hs
/RayNet.
Planningtheinstallation
29
