3.9Datamaster
Anysystemcontainingmorethanonenetworkedmultifunction
displaymusthaveadesignateddatamaster.
Thedatamasteristhedisplaywhichservesasaprimarysource
ofdataforalldisplays,italsohandlesallexternalsourcesof
information.Forexamplethedisplaysmayrequireheading
informationfromtheautopilotandGPSsystems,usually
receivedthroughaSeaTalk
ng
orNMEAconnection.Thedata
masteristhedisplaytowhichtheSeaT alk,NMEAandany
otherdataconnectionsaremade,itthenbridgesthedatato
theSeaTalk
hs
networkandanycompatiblerepeatdisplays.
Informationsharedbythedatamasterincludes:
•Cartography
•Routesandwaypoints
•Radar
•Sonar
•Datareceivedfromtheautopilot,instruments,theengineand
otherexternalsources.
Yoursystemmaybewiredforredundancywithdataconnections
madetorepeatdisplays.Howevertheseconnectionswillonly
becomeactiveintheeventofafaultand/orreassignmentof
thedatamaster.
3.10NewaSeriespartssupplied
Thefollowingitemsaresuppliedwithyourmultifunctiondisplay.
D12 58 3-2
1
4
7
5 6
8
2 3
x4
1Frontbezel
2
Multifunctiondisplay
3Mountinggasket
4
Suncover
5
Trunnionbracketkit
6Documentationpack
7
Powercable
8
4xNuts,bolts,springwashersandwashers(canbeused
foreithersurfaceorbracketmounting.)
Planningtheinstallation
33

Raymarine E70011 - c95 MFD Specifications

General

Display Size	9 inches
Display Type	LCD
Display Resolution	800 x 480 pixels
GPS Receiver	Internal
Waterproof Rating	IPX6
Weight	2.2 kg (4.85 lbs)
Chartplotter	Yes
Touchscreen	Yes
Radar Compatibility	Yes
Sonar Compatibility	Yes
Wi-Fi	Yes
NMEA 2000 Compatible	Yes
Network Compatibility	NMEA 2000
Networking	Ethernet
Sonar	Compatible
