Vesselconstruction
TheconstructionofyourvesselcanhaveanimpactonGPS
performance.Forexample,theproximityofheavystructure
suchasastructuralbulkhead,ortheinterioroflargervessels
mayresultinareducedGPSsignal.Beforelocatingequipment
withaninternalGPSantennabelowdecks,seekprofessional
assistanceandconsideruseofanexternalGPSantenna
mountedabovedecks.
Prevailingconditions
TheweatherandlocationofthevesselcanaffecttheGPS
performance.Typicallycalmclearconditionsprovideforamore
accurateGPSx.Vesselsatextremenortherlyorsoutherly
latitudesmayalsoreceiveaweakerGPSsignal.GPSantenna
mountedbelowdeckswillbemoresusceptibletoperformance
issuesrelatedtotheprevailingconditions.
Viewingangleconsiderations
Asdisplaycontrast,colorandnightmodeperformanceareall
affectedbytheviewingangle,Raymarinerecommendsyou
temporarilypowerupthedisplaywhenplanningtheinstallation,
toenableyoutobestjudgewhichlocationgivestheoptimum
viewingangle.
5.2Mounting-NewaSeries
Viewingangle
000
000
000
000
000
00000
00000
00000
D
12 57 6-1
C
D
A
B
a65/a67
A
60º
B
60º
C60º
D
50º
Note:Theanglesstatedareforacontrastratioofequaltoor
greaterthan10.
Productdimensions
D12 57 9-1
A
C
D
B
E
Item
a65/a67
A
163.57mm(6.44in)
B
143.47mm(5.65in)
C56.6mm(2.23in)
D
167.5mm(6.6in)
E
162.72mm(6.41in)
Mounting
thedisplaycanbesurfacemounted.
Beforemountingtheunit,ensurethatyouhave:
•Selectedasuitablelocation.
•Identiedthecableconnectionsandroutethatthecableswill
take.
•Detachedthefrontbezel.
Locationandmounting
65
