•Alarmofficon—T
ransmitting&Alarmsareswitchedoff
•Datalost—Transmitting.AIStargetlost.
•Nofix—NoGNSS(GPS)fix
•InsufficientCOG/Hdgdata—UnstableCOGorheadingdata
Note:
•IfnoAISmessageisdisplayedthentheAISinenabledandtransmitting.
•Amaximumof25targetscanbedisplayed,wheremorethan25targetsareinrange‘Max
targets
’messageisdisplayedonscreen.
7 .2AIStargetsymbols
DifferentsymbolsareusedtosignifydifferenttypesofAIStarget.
AIStargetsymbols
Standardvessel
Yacht
AidToNavigation(AToN)
Commercialvessel
VirtualAidToNavigation
(AT oN)
Highspeedvessel
Landbasestation
AIS61
