BearingandR
angerequireGNSS(GPS)datatobeavailableonthenetwork.
10
.2ActiveEngineAlarms
Whenenginealarmsareactivetheycanbeviewedfromthe
ActiveEngineAlarmspage
.
The
ActiveEngineAlarmspagecanbeaccessfromthe Alarmsmenu: Menu>Alarms>Active
EngineAlarms
Whenthealarmconditionhasclearedthealarmwillberemovedfromthelist.
10 .3Alarmsettings
Alarmsareusedtoalertyoutoahazardorsituationrequiringyourattention.Alarmsaretriggered
basedontheirspecifiedthresholds.Alarmsaretransmittedonthenetworkthedisplayisconnected
toi.e.:Sea Talk®orSea Talkng®networksfordisplayatothercompatibledevices.
Note:
Inordertosetalarmthresholdsavaliddatasourceforthealarmisrequired.
Depthalarms
Depthalarmscanbeenabledanddisabledandalarmthresholdvaluescanbesetfromthe Depth
menu:Menu>Alarms>Settings>Depth.Thefollowingdepthalarmsareavailable:
•Shallow—TheShallowalarmistriggeredwhenthedetectedwaterdepthisshallowerthanthe
specifiedvalue .
•Deep—TheDeepalarmistriggeredwhenthedetectedwaterdepthisdeeperthanthespecified
value .
•Shallowanchor—TheShallowanchoralarmistriggeredwhenthedetectedwaterdepthis
shallowerthanthespecifiedvalue .
•Deepanchor—TheDeepanchoralarmistriggeredwhenthedetectedwaterdepthisdeeper
thanthespecifiedvalue .
Note:
TheShallowandDeepalarmsareintendedtobeusedwhenunderway .TheShallowanchorand
Deepanchoralarmsareintendedforusewhenatanchor.
Speedalarms
Speedalarmscanbeenabledanddisabledandalarmthresholdvaluescanbesetfromthe Speed
menu:Menu>Alarms>Settings>Depth.Thefollowingspeedalarmsareavailable:
•
BoatSpeedHigh—TheBoatspeedhighalarmistriggeredwhenvesselspeede xceedsthe
specifiedvalue.
Alarms75

Raymarine i70 Specifications

General

Display Type	LCD
Resolution	320 x 240 pixels
Waterproof Rating	IPX6
Interface	SeaTalkng / NMEA 2000
Weight	0.3 kg
Display Size	4.1 inches
Backlighting	LED
Power Supply	12V DC
