8.8NMEA0183connection
TheNMEA0183wirescanbeusedtoconnecttheunittoaNMEA0183GNSS(GPS)receiverorMFD
.
1.Y ellow=Receivepositive(+)wire
2.Green=Receivenegative(-)wire
3.White=Transmitpositive(+)wire
4.Brown=Transmitnegative(-)wire
TheNMEAwiresshouldbeconnectedtoacompatibledeviceasshowninthetablebelow:
NMEA0183wiresNMEA0183device
R eceivepositive(+)
to
Transmitpositive(+)
R eceivenegative(-)
to
Transmitnegative(-)
T ransmitpositive(+)
to
Receivepositive(+)
T ransmitnegative(-)
to
Receivenegative(-)
Cablesandconnections85
