HSB Series LCD Display
2. Press the SYSTEM SET UP soft key.
The SYSTEM SET UP menu is displayed, listing the parameters and their
current settings. The complete list, which you can scroll down, is shown in
the following illustration.
D3650-3
SYSTEM SET UP MENU
DATA BOXES
BEARING MODE
CURSOR REFERENCE
CURSOR READOUT
DAY/NIGHT
HELP
SOFT KEYS
KEY BEEP
MOB DATA
MENU TIMEOUT PERIOD
DISTANCE UNITS
SPEED UNITS
DEPTH UNITS
TEMPERATURE UNITS
VARIATION SOURCE
CURSOR ECHO
DATE FORMAT
TIME FORMAT
TIME OFFSET
LANGUAGE
SIMULATOR
TRUE
RELATIVE
RNG/BRG
RNG/BRG
ON
ON
ON
DR
NO TIMEOUT
NAUTICAL MILES
KNOTS
METRES
CENTIGRADE
AUTOMATIC
DD/MM/YY
24 HOUR
UTC
ENGLISH (UK)
OFF
3. Use the trackpad to move the selection bar down to the LANGUAGE option.
The soft key labels are updated.
4. Use the soft keys to highlight the required language.
5. Press ENTER to return to the setup soft keys.
6. Press CLEAR to return to the normal radar screen.
Radar System Checks and Adjustments
When the display is connected to a scanner unit you should perform the checks
and adjustments detailed below.
Transmission Check
WARNING:
The radar scanner transmits electromagnetic energy. Ensure that the
scanner has been installed according to the recommendations given in the
Pathfinder Radar Scanner Owner’s Handbook, and that all personnel are
clear of the scanner, before switching to transmit mode.
Radar System
Checks and
Adjustments
