Connecting Your Equipment
Before making or changing the connections, switch off the power and disconnect the
power cord from the AC outlet.
Audio/Video Cables
Use audio/video cables (not supplied) to
connect the audio/video components and a
video cable to connect the monitor TV.
Connect red plugs to
R (right), white plugs
to L (left), and the yellow plugs to VIDEO.
Be sure to insert completely.
L
R
VIDEO
Digital Audio Cables/
Optical Cables
Commercially available digital audio coaxial
cables (standard video cables can also be
used) or optical cables (not supplied) are
used to connect digital components to this
receiver.
Be sure to insert completely.
Digital audio coaxial cable
(or standard video cable)
Optical cable
