PUNCH UNIT INST
ALLATION (A812)
SM
1-21
G065
Installation
4.
Install t
he spacer [A] (thi
ckness = 2 mm).
NOTE:
There ar
e thre
e spacers in
the accessory
box. Do not l
ose t
he other
two spacers (
1-mm) because th
ey are used for
adjusti
ng the pu
nch
hole position
.
5.
Install t
he punch unit [B
] and secure it w
ith a long steppe
d screw [C].
6.
Install t
he punch unit kn
ob [D] (
!
x 1).
7.
Secure
the rear
of the p
unch unit (
!
x 2).
A812I765.
W
MF
A812I510.
W
MF
[A]
[D]
[B]
[C]
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA
48
50
