Names of Components
• Do not remove any covers or screws other than those explicitly mentioned in this manual. Inside
this machine are high voltage components that are an electric shock hazard. Contact your sales
or service representative if any of the machine's internal components require maintenance,
adjustment, or repair.
• Do not attempt to disassemble or modify this machine. Doing so risks burns and electric shock.
1. Development unit (Special Color or Black)
2. Fuser unit
3. Development unit (Yellow, Magenta, and Cyan)
4. Cleaning unit for intermediate transfer belt (ITB cleaning unit)
5. Paper transfer unit
