User’s Guide for DG2000 Series
3-4
Example 4: To generate a Pulse Wave
How to generate a Pulse waveform with 5kHz Frequency, 50mV High Level, -5mV Low
Level, 20μs Pulse Width and 10ns Edge Time.
The operation steps:
1. Set the Frequency.
(1) Press Pulse Æ Freq/Period and choose Freq which will display in
reverse color.
(2) Enter “5” from the keypad and choose ” kHz” to set the Frequency as 5 kHz.
2. Set the High Level.
(1) Press Ampl/ HiLev and choose HiLev which will display in reverse
color.
(2) Enter “50” from the keypad and choose the unit “mV
pp” to set the High Level
as 50mV
pp.
3. Set the Low Level.
(1) Press Offset /LoLev to choose LoLev which will display in reverse color.
(2) Enter “-5” from the keypad and choose the unit” mV
dc” to set the Low Level
as -5mV.
4. Set the Pulse Width.
(1) Press DtyCyc/Width and choose Width which will display in reverse
color.
(2) Enter “20” from the keypad and choose the unit “μs” to set the Pulse Width
as 20μs.
5. Set the Edge Time.
(1) Press Edge which will display in reverse color.
(2) Enter “10” from the keypad and choose the unit “ns” to set the Edge Time as
10ns.
