RIGOL
© 2006 RIGOL Technologies, Inc
User’s Guide for DG2000 Series
3-18
Example 12: To generate a Burst Waveform
How to generate a Burst Waveform with the 3 Cycle. The period is 10ms. But you can
not change parameters in the default setting: Internal Source and 0 degree Start
Phase.
The operation steps:
1. Choose the Burst Function:
Press Square, and choose the Square Waveform as the Burst Function.
The default setting of the Source is Internal.
2. Set the Frequency, Amplitude and Offset.
(1) Press Period/Freq and choose Freq which will display in reverse color.
Enter “5” from the keypad and choose the unit “kHz” to set the Frequency as
5 kHz.
(2) Press Ampl/HiLev and choose Ampl which will display in reverse color.
Enter “5” from the keypad and choose the unit “V
pp” to set the Amplitude as
5 V
pp.
(3) Press Offset/LoLev and choose Offset which will display in reverse
color. Enter “0” from the keypad and choose the unit “V
dc” to set the Offset
as 0 V
dc.
You can view the Burst Waveform in the Graph Mode.
3. Set the Burst Mode.
Press Burst Æ NCycle to choose N-Cycle Mode. Please note that the message
shown on the top left side of the screen is “N Cycle”.
4. Set the Burst Period
Press Period , use the keypad to enter “10”, choose the unit “ms” and set the
Period as 10 ms (Please note the icon).
5. Set the Start Phase
Press Phase , use the keypad to enter “0”, choose the unit “°”, setting the Start
phase as 0°.
6. Set the Burst Cycles
Press Cycles , use the keypad to enter “3”, choose the unit “Cyc”, setting the
Burst Cycle as 3.
To Next Page
